20R moving heads
380w beam moving head light 20R moving heads stage lights

380w beam moving head light 20R moving heads stage lights（GM-B380NY）

✨ Spotlight the Stage with 20R Moving Heads! ✨

Unleash brilliant 7500K beams 💡 from a powerful 380W Phoenix bulb! These feature-packed 20R Moving Heads deliver stunning visuals:

  • 540° Horizontal / 270° Vertical Scanning

  • Dual Prisms (8+48) + 14 Patterns + 13-Color Wheel

  • Ultra-Precise Electric Zoom (0-4°) & Focus

  • Smooth 0-100% Dimming & Mechanical Strobe

  • Smart LCD Touch Control & 16-Channel DMX512

  • Auto Cooling, Positioning & Diagnostics

Powerful (500W Total), fast, quiet, and built smart! Master your stage with 20R Moving Heads!

 Contact us
Buy it now

AT A GLANCE

SPECIFICATIONS

DOWNLOADS

VIDEO

RELATED PRODUCTS

AT A GLANCE

  • 380W Phoenix Bulb: High-brightness light source.
  • 7500K Color Temperature: Crisp daylight-like white beam.
  • 540° Horizontal / 270° Vertical Scanning: Extensive movement range.
  • Dual Rotatable Prisms (8 & 48 Facets): With rainbow and atomization effects.
  • 14-Pattern Wheel & 13-Color Wheel + White: Versatile effects and color options.
  • Linear Electric Zoom (0-4°) & Focusing: Precise beam control.
  • Mechanical Strobe: Adjustable speed (up to 15 times/second).
  • LCD Touch-Screen Control: For lamp/bulb status and on/off.
  • DMX512 (16-Channel), Master-Slave, Auto-Run: Flexible control modes.
  • Auto Positioning & Diagnostics: Horizontal/vertical correction and system monitoring.
  • Fast & Quiet Operation: Engineered performance.

Specification

  • Voltage：100V - 240V / 50 - 60Hz
  • Total Power (Bulb + Others)：500W
  • Light Source：380W Phoenix bulb
  • Color Temperature：7500K
  • Average Lifespan：1500 hours
  • Control Channels：DMX512 16 - channel, Master - Slave mode, Auto - run mode
  • Control Interface：LCD touch - screen control interface. Can control bulb on/off function, display lamp and bulb usage time
  • Scanning：Horizontal: 540°, Vertical: 270°
  • Color Disk：One color wheel with 13 colors plus white light
  • Pattern Wheel：14 patterns
  • Prisms：One rotatable 8 - prism and one 48 - prism. The two prisms can be superimposed, with additional rainbow and atomization effects
  • Strobe：Supports mechanical strobe and adjustable - speed strobe effects, supports strobe macro function. Strobe frequency is 15times/second
  • Lens：High - precision optical lens, lens group optical system, electric focusing
  • Beam Angle：0 - 4° linearly adjustable
  • Focusing：Linear electronic focusing
  • Dimming：0 - 100% linear adjustment
  • Lens Diameter：14.5cm / 0.5ft
  • Product Size：31cm/1.0ft * 25cm/0.8ft * 52cm/1.7ft
  • Package Size：55cm/1.8ft * 36cm/1.2ft * 29cm/1.0ft
  • Package Weight:14.9kg / 32.8lb
  • Additional Systems:Automatic horizontal and vertical positioning system. Can preset macro - command controller reset function, with automatic on -off electronic monitoring and position error correction. Built - in cooling monitoring system, DMX channel level monitoring, andautomatic data transmission fault diagnosis system
  • Characteristics：High - brightness, fast, quiet

DOWNLOADS

380w beam moving head light 20R moving heads stage lights（GM-B380NY）Reference Guide Downloads

VIDEO

Frequently Asked Questions

Q: What is the light source and lifespan of the 20R Moving Heads?

A: It uses a high-brightness 380W Phoenix bulb with an average lifespan of 1500 hours.

Q: How much movement range does the 20R Moving Heads offer?

A: It provides extensive scanning with 540° horizontal and 270° vertical movement.

Q: What control options are available for the 20R Moving Heads?

A: It supports DMX512 (16-channel), Master-Slave mode, Auto-run mode, and features an LCD touch-screen control interface.

Q: What optical effects does the 20R Moving Heads include?

A: It features a rotatable 8-prism and 48-prism (with rainbow/atomization), a 13-color wheel + white, a 14-pattern wheel, and adjustable mechanical strobe.
