1000W LED Moving Head with CMY & CTO & Framing & Gobo（GL-HP1000）

1000W LED | 5°–50° Zoom | CMY + CTO | 8-Blade Framing | 20,000h Lifespan

Overview

A professional-grade 1000W LED moving head featuring CMY infinite color mixing, linear CTO, dual gobo wheels (rotating + fixed), animation wheel, 8-blade framing system, and dual frost/prism effects. 5°–50° zoom range. Built for concerts, theaters, and touring productions

Color temperature: 6700K–8000K native
Color system: CMY + linear CTO (2700K–6700K)
Color wheel: 6–7 colors + open
Gobos: 7 rotating glass gobos + 8–11 static gobos
Framing: 4 rotating shutters with ±60° module rotation
Prisms: 4/6-facet rotating prisms
Control: DMX512, RDM (Art-Net/sACN optional)

AT A GLANCE

900W High-Output LED Source
Delivers powerful, consistent illumination with a 20,000-hour LED lifespan, making it ideal for concerts, touring, theatres, clubs, and professional event lighting.
Advanced CMY Color Mixing & CTO
Provides smooth CMY infinite color mixing with linear CTO adjustment from 2700K to 6800K for precise color control and natural white-light transitions.
Precision Framing & Beam Control
An 8-blade framing system with ±60° rotation works with a 5-50° linear zoom to create accurate beam shaping, sharp cuts, and versatile stage effects.
Creative Gobo, Prism & Dynamic Effects
Features rotating and fixed gobos, 5-facet and 5-facet linear prisms, plus dynamic fire and water effects for distinctive aerial looks and visual textures.
Professional Motion & Control System
16-bit pan and tilt movement, electronic focus, smooth 0-100% dimming, high-speed strobe, and DMX512, RDM, Art-Net, and optional Wireless DMX support offer flexible control for demanding productions.

Specification

Power Supply:AC100-240V, 50/60Hz
Power Consumption:1050W
Light Source:900W White LED Module
Color Temperature:6800K
LED Lifespan:20000 Hours
Beam Uniformity:90%
Pan:540 Degree (16-bit, 0.008 Degree)
Tilt:270 Degree (16-bit, 0.008 Degree)
Color System:CMY Infinite Mixing, CTO Linear 2700K-6800K
Color Wheel:7 Fixed Colors + White
Rotating Gobo Wheel:7 Rotating Gobos + White
Fixed Gobo Wheel:10 Fixed Gobos + White
Effect Wheel:Dynamic Fire / Water Effects
Prism:5-Facet + 5-Facet Linear Prism
Focus:Electronic Focus

Iris:5%-100% Smooth
Strobe:Up to 25Hz, 1-13 Flashes/Sec
Dimmer:0-100% Linear
Frost:1 Light Frost + 1 Medium Frost
Zoom:5-50 Degree Linear
Framing System:8 Blades, +/-60 Degree Rotation
Control Modes:39/41/62 DMX512 Channels, RDM, Art-Net, Wireless DMX (Optional)
Display:2.4 Inch LCD, CN/EN, 180 Degree Flip
Dimming Curves:4 Curves, 16-bit Precision
Refresh
Rate:800Hz/1200Hz/3600Hz/5000Hz/10kHz/15kHz/20kHz/25kHz
Gross Weight:33kg / 72.8lb
Carton Size:830×450×370mm / 2.7×1.5×1.2ft
Flight Case (2-in-1):110×88×59cm / 3.6×2.9×1.9ft, 120kg

VIDEO

Frequently Asked Questions

Q: What is the power consumption of this LED Moving Head?

A: This LED Moving Head has a 1050W power consumption and uses a 900W white LED module as its light source. It is designed for professional stage lighting applications where high output, reliable performance, and long operating life are important.

Q: What color mixing system does this LED Moving Head use?

A: The fixture features CMY infinite color mixing with a linear CTO range from 2700K to 6800K. This allows lighting designers to create a wide range of colors and achieve smooth color temperature adjustments for concerts, theatres, events, clubs, and touring productions.

Q: Does the LED Moving Head have a framing system and adjustable zoom?

A:Yes. It features an 8-blade framing system with +/-60° rotation and a 5-50° linear zoom. This combination provides precise beam shaping and flexible coverage, making the fixture suitable for both wide-area stage lighting and more focused effects.

Q: What lighting effects and gobos are included?

A: This professional LED Moving Head includes 7 rotating gobos, 10 fixed gobos, a 7-color wheel plus white, dynamic fire/water effects, and both 5-facet and 5-facet linear prisms. It also provides electronic focus, smooth iris control, frost effects, and strobe functionality for a broad range of creative lighting looks.

Q: What control protocols and DMX modes are supported?

A: The fixture supports 39, 41, or 62 DMX512 channels, along with RDM and Art-Net. Wireless DMX is optionally available, providing flexible integration into professional lighting control systems for stage productions, concerts, events, theatres, and entertainment venues.
