200W Fixed Focus Led Profile Spot（GL-200E）

Engineered for professionals, the GL-200E delivers broadcast-grade color accuracy and seamless control for studio, stage, and architectural applications.

Precision Color & Performance
• 200W COB RGBWA LED with Color Calibration System (CCS) ensures consistent, vibrant color across multiple fixtures.
• CRI >95 and true-to-life color rendering for critical on-camera applications.
• Flicker-free dimming (1200Hz–20000Hz) with smooth 0–100% control and four customizable dimming curves.

Professional Control & Reliability
• Multiple control options: DMX512, RDM, standalone, and Light Captain.
• Robust housing, efficient cooling, and P-Con connections.
• Compact and durable design for both touring and fixed installation.

AT A GLANCE

High-Frequency PWM Dimming: The fixture features an adjustable PWM dimming frequency ranging from 1200Hz to 20000Hz, which ensures flicker-free operation across various lighting environments and camera settings.
Smooth Dimming Experience: With a 0-100% linear dimmer and four selectable dimming curves, users can achieve a smooth and precise dimming effect, perfect for creating subtle lighting transitions.
Advanced Color Calibration System (CCS): The fixture is equipped with a sophisticated Color Calibration System, ensuring consistent and accurate color reproduction across multiple units, which is essential for professional lighting setups.
Customizable Control Experience: The combination of these control modes allows for a highly customizable lighting experience, catering to the needs of both novice users and experienced lighting designers.
High CRI for Accurate Color Representation: With a Color Rendering Index (CRI) of over 95, the fixture ensures true-to-life color rendering, making it ideal for applications requiring high color fidelity.

Specification

Power:AC100V~240V, 50/60Hz--200W
CRI: >95
Control Mode:RDM; DMX512; HSIC; Master/Slave; Stand-alone
Adjust: (1200Hz ~ 20000Hz)
Color Calibration:System (CCS)
Power connection:Mains input P-Con (blue) mounting version
Lamp type:LED lamp
Cooling:Cooling fan
Control:RDM; DMX; stand-alone; Light Captain
DMX input:3-pin XLR (M) mounting version
Color rendering index (CRI) more than:95 Ra
Weight:8.4kg (18.52 lbs)

LEDs:COB 200W LED 5in1-RGBWA
Beam Angle:19°, 26°, 36°, 50°
Dimmer:0-100% linear dimmer; 4 selectable dimming curves，PWM Dimming Frequency:
Protection class:Class I
Power output:P-Con (gray) mounting version
LED:1 x COB (chip-on-board) 200 W
DMX output:3-pin XLR (F) mounting version
Beam angle (1/2 peak):19°, 26°, 36°, 50°
Housing color:Black
Display type:LCD
Length: 54.5cm (21.45 inches) * Width: 27.2cm ( 10.71 inches) * Height: 22.2 cm ( 8.74 inches)

DOWNLOADS

200W Fixed Focus Led Profile Spot reference guide downloads

VIDEO

Frequently Asked Questions

Q: What is the significance of the high Color Rendering Index (CRI) over 96?

A: A CRI over 96 ensures that the light fixture delivers exceptionally accurate color rendering, which is crucial for applications that require true color representation, such as photography, film, and stage lighting.

Q: How does the fixture's dimming capability enhance the lighting experience?

A: With a 0-100% linear dimmer and four selectable dimming curves, the fixture allows for precise control over light intensity, enabling users to create various lighting moods and effects for different applications.

Q: What is the role of the LCD display in the fixture's operation?

A: The LCD display provides a user-friendly interface for monitoring and controlling the fixture's settings, making it easier to adjust parameters such as dimming, color calibration, and other functions without the need for external control equipment.
