Z2 GrandMA foldable DMX controller

Be the Maestro of Light! Meet Your New Professional DMX Controller

Core Power:
• Windows 10 OS on a powerful Intel i5 CPU with SSD speed!
• Built-in UPS - Never miss a beat, even if the power does!

Stunning Visual Control:
• Dual 15.6" foldable capacitive touch displays!
• Connect extra monitors via HDMI or VGA. See all the magic!

Massive Connectivity:
• 6 DMX outputs & 1 input for total command!
• Art-Net & gigabit network port for wireless freedom!
• LTC Timecode, MIDI In/Out for perfect sync with your show!

Hands-On Control:
• 1 Master wheel + 4 attribute wheels for precision tweaking!
• 21 playback faders + 42 function keys - Your creativity is unleashed!

Built Tough:
• All this power in one rugged road-ready case!
• Weight: 36kg | Size: 88x48x35cm

AT A GLANCE

Dual 15.6" Foldable Touchscreens: Command your show with two high-resolution capacitive touch displays on a Windows 10 platform, offering unparalleled flexibility and visual feedback.
Robust 6-Port DMX Controller: Unleash full control over large-scale lighting setups with six independent DMX outputs and comprehensive Art-Net support for ultimate networking freedom
Built-in UPS Power Supply: Ensure a flawless, uninterrupted performance with the integrated UPS, safeguarding your show against unexpected power disruptions.
Extensive Playback Control: Manage your show effortlessly with 21 dedicated playback faders and 42 function keys, allowing for rapid access to cues and scenes.
Multi-Protocol Connectivity: Synchronize seamlessly with other equipment using the dedicated LTC timecode input and MIDI In/Out interfaces.

Specification

Windows10 system
Intel Core i5 CPU, 4GB RAM, 120GB SSD
Two 15.6-inch foldable capacitive touch display
6 DMX outputs, 1 input (composite)
1 LTC time code input interface, 1 MIDI input interface and 1 MIDI output interface
1 gigabit network port, support MANET, ARTNET
Can be connected to an external HDMI display,1 VGA external display port

1 master dimmer wheel, 4 attribute encoding wheels
1 master pusher, 2 AB pusher, 21 program playback pusher, 42 program storage function keys
4 USB ports, 2 working light port
Built-in UPS power supply
Input voltage: 110V~220V 50~60Hz
Package size: 88*48*35CM
Weight: 36KG

DOWNLOADS

Z2 GrandMA foldable DMX controller Reference Guide Downloads

Frequently Asked Questions

Q: What operating system does this DMX controller use, and can I install other software on it?

A: It runs on a dedicated Windows 10 system. While it's a full Windows PC, it's optimized for stable lighting control. It's not recommended to install unrelated software to avoid potential conflicts or viruses.

Q: How many DMX universes can this lighting console control?

A: With 6 physical DMX outputs and a gigabit network port supporting Art-Net, this controller can handle multiple DMX universes simultaneously, making it perfect for complex, large-scale lighting setups.

Q: Does it have a backup power feature for live events?

A: Yes! A key feature is its built-in UPS (Uninterruptible Power Supply). This provides critical backup power, allowing you to safely shut down the console during an unexpected power failure, protecting your show and equipment.

Q: What options are there for external synchronization and control?

A: It offers versatile sync options with 1 LTC (Linear Time Code) input for audio/video synchronization and both MIDI In and Out interfaces for triggering cues or controlling other MIDI-compatible gear.
