100W 9°-25° Zoom Ellipsoidal LED Theatre Stage Lighting（GL-100BS-RGBALC）


Rich colors: RGBALC: Red, Green, Blue, Amber, Lemon, Cyan, can achieve almost unlimited color changes, providing stage lighting designers with more creativity and expression space to create colorful stage effects.

Flexible adjustment: 9°-25° adjustable beam angle and multiple functional adjustment features enable it to more flexibly adapt to different stage scenes and performance requirements, improving the accuracy and flexibility of lighting design.


 Contact us
Buy it now

AT A GLANCE

SPECIFICATIONS

DOWNLOADS

VIDEO

RELATED PRODUCTS

AT A GLANCE

  • High-Quality Lighting: Equipped with a COB 100W 6-in-1 LED (RGBALC) with a high CRI of over 96, ensuring accurate color rendering and vibrant illumination.
  • Adjustable Beam Angle: Features a flexible beam angle range from 9° to 25°, allowing precise control over light coverage.
  • Multiple Control Options: Supports various control modes including RDM, DMX512, HSIC, Master/Slave, and Stand-alone, making it versatile for different lighting setups.
  • Smooth Dimming: Offers 0-100% linear dimming with four selectable dimming curves, enabling smooth and gradual light adjustments.
  • Adjustable PWM Dimming Frequency: Provides a dimming frequency adjustment range from 1200Hz to 20000Hz, suitable for flicker-free operation in video and photography applications.

Specification

  • Power：AC100V~240V, 50/60Hz, 100W
  • LEDs：COB 100W LED 6in1-RGBALC, CRI: > 96
  • Beam Angle：9°-25°
  • Control Mode：RDM, DMX512, HSIC, Master/Slave, Stand-alone
  • Dimming：0-100% linear dimmer, 4 selectable dimming curves
  • PWM Dimming Frequency：Adjustable from 1200Hz to 20000Hz
  • Color Calibration System：CCS
  • Protection class:Class I
  • Power connection:Mains input P-Con (blue) mounting version
  • Power output:P-Con (gray) mounting version
  • Lamp type:LED lamp
  • LED:1 x COB (chip-on-board) 100 W
  • DMX input:3-pin XLR (M) mounting version
  • DMX output:3-pin XLR (F) mounting version
  • Cooling:Cooling fan
  • Control:RDM; DMX; stand-alone; Light Captain
  • Beam angle (1/2 peak):9°-25°
  • Color rendering index (CRI) more than:96 Ra
  • Housing color:Black
  • Display type:LCD
  • Dimensions:Length: 46.2cm (≈ 18.2 inches) * Width: 17.8cm (≈ 7 inches) * Height: 24 cm (≈ 9.45 inches)
  • Weight:4.2kg (≈ 9.24 lbs)

DOWNLOADS

100W 9°-25° Zoom Ellipsoidal LED Theatre Stage Lighting reference guide downloads

VIDEO

Frequently Asked Questions

Q: What is the beam angle range of this LED light?

A:The beam angle can be adjusted from 9° to 25°, allowing for versatile lighting applications.

Q: How is this product controlled?

A: It supports various control modes, including RDM, DMX512, HSIC, Master/Slave, Stand-alone, and Light Captain.

Q: Does this light offer adjustable dimming?

A: Yes, it provides 0-100% linear dimming with four selectable dimming curves for precise brightness control.

Q: What is the color rendering index (CRI) of this LED?

A: The CRI is over 96, ensuring high-quality color accuracy and vibrant lighting.
